Mitutoyo 3415A | Dial Gauge | Lug Back | ANSI/AGD Type | Series 3 | Graduation 0.001 inch | Range 0.5 inch
Part No. 3415A | Range 0.5 inch | Graduation 0.001 inch
General Tech Services LLC — Genuine Mitutoyo Distributor, Kuwait +965 9807 4888
Product Overview
The Mitutoyo 3415A is an ANSI/AGD-type Series 3 dial gauge with a lug back design, 0.001 inch graduation and a 0.5 inch measuring range. Its mechanical movement supports dependable comparative measurement of heights, steps, runout and machine alignment.
The 0.5 inch range provides extended travel for inspection tasks while maintaining 0.001 inch resolution. The lug back provides a dedicated rear mounting point for securing the gauge to suitable brackets, fixtures or machines where lug mounting is preferred.
The 3415A is made to American Gage Design dimensions, supporting compatibility with commonly used inspection stands, holders and fixtures. For applications requiring a flat back configuration, see the Mitutoyo 3415AB.
Key Benefits
■ 0.001 inch graduation for clear, practical readings
■ 0.5 inch measuring range for extended-travel inspection
■ ANSI/AGD standard design for compatibility with common stands, holders and accessories
■ Lug back for direct mounting to suitable brackets and fixtures
■ Robust mechanical movement for dependable workshop use
■ Genuine Mitutoyo part supplied and supported locally in Kuwait
Who This Product Is Best For
■ Inspectors measuring heights, steps and runout over an extended stroke
■ Toolrooms and machine shops setting up workpieces, fixtures and machine alignment
■ Maintenance teams replacing an existing ANSI/AGD lug back dial gauge
■ Calibration and inspection teams standardising equipment on Mitutoyo
How to Use It
-
Mount the gauge using its lug back or compatible stem arrangement on a rigid bracket or fixture, with the plunger correctly aligned with the measuring surface.
-
Apply suitable preload and rotate the bezel to set zero against a reference surface or master.
-
Move the workpiece or gauge across the feature and read the pointer movement to determine the deviation.
-
Retract the plunger carefully after measurement and store the gauge clean, dry and protected.
Frequently Asked Questions
What is the Mitutoyo 3415A dial gauge used for?
The 3415A is designed for comparative measurement of heights, steps, runout and machine alignment. Its 0.001 inch graduation and 0.5 inch range support extended-travel inspection.
What are the graduation and range of the 3415A?
The gauge has a 0.001 inch graduation and a 0.5 inch measuring range.
What does ANSI/AGD mean on the 3415A?
ANSI/AGD refers to the American Gage Design standard for dial indicators. Standardized dimensions help support compatibility with commonly used stands, holders and inspection accessories.
What is the benefit of a lug back?
The lug back provides a dedicated mounting point that can be used to secure the gauge to a suitable bracket or fixture.
What is the difference between the 3415A and 3415AB?
Both models have a 0.001 inch graduation and a 0.5 inch measuring range. The 3415A has a lug back, while the 3415AB has a flat back configuration.
Is the genuine Mitutoyo 3415A available in Kuwait?
Contact General Tech Services LLC at +965 9807 4888 for current pricing, lead time and availability.
Request Pricing & Availability
For genuine Mitutoyo 3415A dial gauges in Kuwait, contact General Tech Services LLC at +965 9807 4888 for pricing and current stock availability.
