Name: Mitutoyo 543-401B | Digital Indicator ID-C | 0.5 in / 12.7 mm, 0.01 mm
Brand: Mitutoyo
SKU: 543-401B
Availability: OutOfStock

Part Number : 543-401B

Mitutoyo 543-401B is a Digital Indicator ID-C offering 0.5 in or 12.7 mm of travel and a finest step of 0.01 mm. It is rated at ±0.02 mm accuracy.

Availability: in stock

Free Kuwait shipping available

Part Number	543-401B
Brand	Mitutoyo
Range	0.5 in or 12.7 mm
Digital Step / Resolution	0.01 mm
Accuracy (MPE)	±0.02 mm
Measuring Force	less than 0.9 N
Stem Diameter	8 mm
Battery Life	Approx. 5,000 hours under normal use
Display	LCD
Functions	Digimatic data output

Comparable in dimensions to typical Series 2 dial indicators
Both metric and inch/metric variants are available.
Real-time data handling is made quick and simple by the SPC output function.
Setting the origin point each time the micrometer is turned on is no longer necessary thanks to the ABSOLUTE (ABS) linear scale.
Even when data is re-displayed after disappearing because of inadequate light while in use, an origin reset is not necessary.
When upper and lower tolerances are specified, the G0/No-Go display turns red or green.
There are internal computations available using the straightforward formula [F(x)=Ax].
Among the functions are Origin set, zero sets, Go/No-Go decision-making, direction-counting switching, power-on/off, data output, and conversion between inches and millimeters (only on inch/metric models)
Alarms include low voltage, overflow, counting value composition, and tolerance limit setting errors.
Over-speed errors are eliminated by unlimited response speed.
IP42 is the dust/water protection level.
packaged in a custom-fit plastic case
Included is an inspection certificate.
