Mitutoyo 178-581-02E | Surftest SJ-411 Portable Surface Roughness Tester | 5 µm Stylus

Name: Mitutoyo 178-581-02E | Surftest SJ-411 Portable Surface Roughness Tester | 5 µm Stylus
Brand: Mitutoyo
SKU: 178-581-02E
Availability: OutOfStock

Part Number : 178-581-02E

Mitutoyo 178-581-02E is a Surftest SJ-411 portable roughness tester fitted with a 5 µm, 60° stylus tip, reading in inch or metric. Speeds can be set from 0.05 to 1 mm/s, and BAC and ADC graphs support analysis.

5 µm / 60° diamond stylus tip
Measuring speeds 0.05-1 mm/s in five steps
AC adapter or rechargeable battery
Range 800 / 80 / 8 µm, up to 2.4 mm with an optional stylus
EN ISO, VDA, JIS, ANSI and custom settings

Availability: in stock

Free Kuwait shipping available

Specifications
Features
Downloads

Part Number	178-581-02E
Brand	Mitutoyo
Model	Surftest SJ-411
Stylus	Diamond, 5 µm tip, 60°
Units	Inch/Metric
Range	800 µm; 80 µm; 8 µm (up to 2,4 mm with an optional stylus)
Measuring Speed	0.05 mm/s; 0.1 mm/s; 0.2 mm/s; 0.5 mm/s; 1 mm/s
Digital Filters	Gauss, 2CR75, PC75
Profiles	Primary Profile (P), Roughness Profile (R), Waviness (W), MOTIF (R, W) and more
Standards	EN ISO, VDA, JIS, ANSI and customize settings
Detection	Skidless - Differential inductance
Power Supply	AC adapter or rechargeable battery

This is a portable measuring instrument that allows you to easily and accurately measure surface roughness.

The Surftest SJ-410 offers you the following benefits:

Skidless system with touch-screen functionality and built-in printer.
It works independently of mains power, allowing you to make on-site measurements.
Easy and intuitive menu navigation.
The large 14.5 cm [5.7“] colour LCD gives you high visibility.
The skidless detector allows you to measure the primary profile (P), roughness profile (R),
waviness profile (W) and more.
Surface compensation of curved, radial and tilted surfaces.
It performs roughness analyses conform to various international standards (EN ISO, VDA, ANSI, JIS) and customized settings.
You can store up to 10 different measuring conditions inside the SJ-410, and up to 500 with an optional SD card.
It allows two different evaluation conditions within one measurement adjustable.
You can separately password protect many functions.
It comes with support for 16 languages.
Available options include an auto-set unit, X-axis fine adjustment and digital levelling unit.
