OMRON E2EW-X10C318-M1 | M18 Inductive Proximity Sensor | 10 mm Range, NPN NO+NC, M12 Connector

Name: OMRON E2EW-X10C318-M1 | M18 Inductive Proximity Sensor | 10 mm Range, NPN NO+NC, M12 Connector
Brand: OMRON
SKU: E2EW-X10C318-M1
Availability: OutOfStock

Part Number : E2EW-X10C318-M1

With an M12 connector and NPN NO+NC outputs, the OMRON E2EW-X10C318-M1 is an inductive sensor that detects targets at up to 10 mm from an M18 threaded barrel. Supply voltage for the E2EW-X10C318-M1 is 10 to 30 V DC, and the housing is rated IP67 with a 41 mm body length.

Flush mounting, shielded
Switching current: 200 mA
Operating temperature 0 to +85 °C
OMRON E2EW series

Availability: in stock

Detailed Description
Specifications

The Omron E2EW series shielded proximity sensor offer equivalent sensing distances for both iron and aluminium. Laser printing sensing distance on its active face to prevent replacement errors. It has 10 mm sensing distance and robust full stainless steel housing with metal sensing face.

Flush mounted
NO + NC operation mode
UL and CSA certification
IP67 degree of protection (IP)

Brand	Omron
Thread Size	M18
Sensor Technology	Inductive
Detection Range	10 mm
Body Style	Threaded Barrel
Digital Switching Output Type	NPN
Output Function	NO+NC
Connection Type	M12
Supply Voltage	10 → 30 V dc
IP Rating	IP67
Length	41mm
Mounting Type	Flush
Maximum DC Voltage	30V
Minimum Operating Temperature	0°C
Shielding	Shielded
Switching Current	200 mA
Maximum Switching Frequency	2Hz
Series	E2EW
Maximum Operating Temperature	+85°C
Switching Frequency	2 Hz
