Name: Omron E3JM-DS70M4-G, Diffuse Photoelectric Sensor, Block Sensor, 700 mm Detection Range
Brand: OMRON
SKU: E3JM-DS70M4-G
Availability: OutOfStock

Omron E3JM-DS70M4-G, Diffuse Photoelectric Sensor, Block Sensor, 700 mm Detection Range

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron E3JM-DS70M4-G, Diffuse Photoelectric Sensor, Block Sensor, 700 mm Detection Range

Part Number : E3JM-DS70M4-G

Availability: Sold out

Detailed Description
Specifications

Omron E3JM Series Photoelectric Sensor, 700mm Sensing Distance, 30ms Response Time - E3JMDS70M4G

This photoelectric sensor with a built-in power supply operates effectively over a detection range of 700mm. It is suitable for various environments with ambient temperatures from -25°C to 55°C and has an IP66 rating, ensuring durability in challenging conditions.

Features & Benefits

• Detection range of 700mm for versatile applications
• Infrared sensor for non-contact operation
• IP66 rating provides protection from dust and water
• Extensive operating temperature range of -25°C to +55°C

Applications

• Conveyor system monitoring
• Packaging machinery for object detection
• Assembly lines for quality control
• Material handling systems for safety measures

Will it require special wiring during installation?

Standard 5 terminal screw connections will suffice.

How does it detect objects?

It uses an infrared beam to sense objects within range.

Brand	Omron
Sensor Style	Block
Detection Type	Diffuse
Detection Range	700 mm
Output Type	Relay
Electrical Connection	5 Terminal Screw
Maximum AC Voltage	240V
Maximum DC Voltage	240V
Terminal Type	Block
Light Source	Infrared
IP Rating	IP66
Maximum Current	3 A
Response Time	30 ms
Series	E3JM
Housing Material	ABS
Maximum Operating Temperature	+55°C
Minimum Operating Temperature	-25°C
Standards Met	CCC, CE, CSA, UL
