OMRON G2RG-2A-X DC24 | PCB Power Relay | 24 V DC Coil, 10 A, DPST

Name: OMRON G2RG-2A-X DC24 | PCB Power Relay | 24 V DC Coil, 10 A, DPST
Brand: OMRON
SKU: G2RG-2A-X DC24
Availability: OutOfStock

Part Number : G2RG-2A-X DC24

The OMRON G2RG-2A-X DC24 is a PCB-mount G2RG series power relay with a 24 V DC coil and DPST contacts, rated for 10 A switching current. Other listed details: a coil resistance of 720 Ω and 800 mW coil power.

2-pole DPST contact form
10 kV isolation between coil and contacts
Mounting: PCB Mount

Availability: in stock

Detailed Description
Specifications
Downloads

The Omron G2RG series of power relay with 24 Vdc and 10 A switching capacity. It has a 2 poles series wiring with 3.0 mm contact gap. Used for energy storage system.

Achieves 500 VDC 10 A switching capacity used with 2 pole series wiring
3.0 mm contact gap (2 poles series wiring)
Offers high insulation with insulation distance above 8 mm and
impulse withstand voltage of 10 kV between coil and contacts.
UL and TÜV cert

Brand	Omron
Coil Voltage	24V dc
Contact Configuration	DPST
Mounting Type	PCB Mount
Switching Current	10A
Number of Poles	2
Series	G2RG
Coil Resistance	720 Ω
Coil Power	800mW
Isolation Coil To Contact	10kV
Number of Coils	Single
