Name: Omron G6AK-274P-ST-US 24DC, PCB Mount Latching Signal Relay, 24V dc Coil, 500mA Switching Current, DPDT
Brand: OMRON
SKU: G6AK-274P-ST-US 24DC
Availability: OutOfStock

Omron G6AK-274P-ST-US 24DC, PCB Mount Latching Signal Relay, 24V dc Coil, 500mA Switching Current, DPDT

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron G6AK-274P-ST-US 24DC, PCB Mount Latching Signal Relay, 24V dc Coil, 500mA Switching Current, DPDT

Part Number : G6AK-274P-ST-US 24DC

Availability: Sold out

Detailed Description
Specifications
Downloads

G6A Series DPCO Latching

Fully sealed
Low magnetic leakage
Impulse withstand voltage of 1500V
Ideal for telecommunications equipment

Approvals

UL, CSA

Brand	Omron
Coil Voltage	24V dc
Contact Configuration	DPDT
Mounting Type	PCB Mount
Maximum Switching Current AC	500 mA
Maximum Switching Current DC	500 mA
Maximum Switching Voltage AC	250V ac
Maximum Switching Voltage DC	220V dc
Maximum Switching Power DC	60 W
Length	20.2mm
Latching	Yes
Depth	10.1mm
Height	8.4mm
Dimensions	20.2 x 10.1 x 8.4mm
Terminal Type	Through Hole
Application	Signal
Switching Current	500mA
Electrical Life	500000 Operations
Coil Power	180mW
Contact Material	Gold Plated

Omron G6AK-274P-ST-US 24DC, PCB Mount Latching Signal Relay, 24V dc Coil, 500mA Switching Current, DPDT
