OMRON G6EU-134P-US 12DC | Latching Signal Relay | 12 V DC Coil, SPDT, 3 A, PCB Mount
This SPDT latching signal relay, the OMRON G6EU-134P-US 12DC, is driven by a 12 V DC coil and handles 3 A in a PCB-mount format. The G6EU-134P-US 12DC (12 V DC version) has a maximum switching voltage of 250 V AC / 220 V DC and switching power up to 60 W DC / 50 VA AC. Its 12 V DC coil has a resistance of 720 Ω.
- Dimensions: 16 x 8 x 10 mm
- Terminals: through hole
- Max switching current: 3 A AC / 3 A DC
- Maximum operating temperature: +70 °C
- Listed application: signal
- Latching: yes
- Detailed Description
- Specifications
- Downloads
G6E Series
Fully sealed construction allows immersion cleaning of PCB
High sensitivity
Impulse withstand voltage meets FCC Part 68 requirements
Approvals
| Brand | Omron |
| Coil Voltage | 12V dc |
| Contact Configuration | SPDT |
| Mounting Type | PCB Mount |
| Switching Current | 3A |
| Maximum Switching Current DC | 3 A |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 220V dc |
| Maximum Switching Power DC | 60 W |
| Length | 16 mm (0.630 in) |
| Latching | Yes |
| Depth | 10 mm (0.394 in) |
| Height | 8 mm (0.315 in) |
| Dimensions | 16 x 8 x 10 mm (0.630×0.315×0.394 in) |
| Terminal Type | Through Hole |
| Application | Signal |
| Coil Resistance | 720Ω |
| Maximum Operating Temperature | +70 °C (158 °F) |
| Maximum Switching Current AC | 3 A |
| Maximum Switching Power AC | 50VA |
