OMRON MY2IN-GS-R AC220/240 | MY-GS Plug-In Miniature Relay with Indicator | DPDT, 10 A, 220/240 VAC
The MY2IN-GS-R is a DPDT miniature power relay from the OMRON MY-GS series. This version has a 220/240 VAC coil and a 10 A rating at 250 VAC / 30 VDC. It is used for general switching in control panels.
Key features
- DPDT contacts, 10 A at 250 VAC / 10 A at 30 VDC (resistive)
- 220/240 VAC coil
- Operation indicator and latching lever
- Max. switching capacity 2,500 VA / 300 W (resistive)
- Mechanical life 50,000,000 operations
- Electrical life 100,000 operations at 10 A, 250 VAC
- Specifications
- Features
- Downloads
| Part Number | MY2IN-GS-R AC220/240 |
| Brand | OMRON |
| Series | MY-GS |
| Coil Voltage | 220/240 VAC |
| Contact Material | Silver (Ag) |
| Contact Form | DPDT (2-pole) |
| Indicator | Operation indicator and latching lever |
| Mechanical Life | 50,000,000 operations |
| Rated Load (Resistive) | 10 A at 250 VAC / 10 A at 30 VDC |
| Max. Switching Capacity | 2,500 VA / 300 W |
| Ambient Operating Temperature | -40 to 70 degC (models with LED indicator) |
Relay, plug-in, 8-pin, DPDT, 10 A, mechanical & LED indicators, lockable push test button, 220/240 VAC
