OMRON MY4-GS-R DC24 | Plug-In Power Relay | 24 V DC Coil, 4PDT, 6 A
Rated for 6 A switching current, the OMRON MY4-GS-R DC24 is a 4PDT plug-in power relay driven by a 24 V DC coil. The 14-pin plug-in base comes with a mechanical indicator, with a coil resistance of 662 Ω (coil power 900 mW).
- Maximum switching voltage 250 V AC / 220 V DC
- Maximum switching current 6 A AC / 6 A DC
- Coil-to-contact isolation 2 kV AC
- Dimensions 28 x 36 x 36 mm (L x H x D)
- Non-latching operation
- 4 poles (4PDT)
- Detailed Description
- Specifications
- Features
- Downloads
OMRON Power Relay, 14-Pin Connector, Silver Contacts - MY Series - MY4-GS-R DC24
Features & Benefits
• Conductive silver pins achieve reliable electrical connections
• Four-pole contact layout means it can control multiple circuits at once
• Broad operating temperature range between -55°C and +70°C to handle tough settings
Applications
• Packaging industry
• Electronics manufacturing
Why should I use a plug-in power relay?
How many times an hour can this product switch?
Note
| Brand | Omron |
| Series | MY |
| Coil Voltage | 24V dc |
| Contact Configuration | 4PDT |
| Mounting Type | Plug In |
| Switching Current | 6A |
| Number of Poles | 4 |
| Latching | No |
| Coil Resistance | 662 Ω |
| Terminal Type | Plug In |
| Length | 28 mm (1.10 in) |
| Maximum Operating Temperature | +70 °C (158 °F) |
| Coil Power | 900mW |
| Height | 36 mm (1.42 in) |
| Depth | 36 mm (1.42 in) |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Isolation Coil To Contact | 2kV ac |
| Maximum Switching Current DC | 6 A |
| Maximum Switching Current AC | 6 A |
Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical indicator, 24 VDC
