Omron MY4IN-GS-R AC24, Plug In Latching Power Relay, 24V ac Coil, 6A Switching Current, 4PDT

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron MY4IN-GS-R AC24, Plug In Latching Power Relay, 24V ac Coil, 6A Switching Current, 4PDT

Name: Omron MY4IN-GS-R AC24, Plug In Latching Power Relay, 24V ac Coil, 6A Switching Current, 4PDT
Brand: OMRON
SKU: MY4IN-GS-R AC24
Availability: OutOfStock

Part Number : MY4IN-GS-R AC24

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical & LED indicators, lockable push test button, 24 VAC

Availability: Sold out

Detailed Description
Specifications
Features

OMRON Power Relay, 900mW Coil Power, 180Ω Coil Resistance - MY Series - MY4IN-GS-R AC24

Do you need a clever piece of kit to bring your industrial system to life? Use this 4PDT power relay from OMRON. It turns 24V AC devices like fans, pumps and motors on and off in a snap. Plug-in mounting makes installation a breeze. You can even speed up wiring by up to 60% by using a push-in socket (111-3063). As it carries out up to 2400 operations per hour, this is a reliable choice. With a high dielectric strength of 2kV, the component holds its own against sudden surges for up to one minute, protecting your equipment from damage and minimising downtime.

Features & Benefits

• 0.9W power consumption during operation for energy-efficiency
• Light 35g weight won't strain the socket
• Handy LED for easy monitoring and diagnostics
• Small dimensions of 36 (H) x 21.5 (W) x 28mm (L) take up minimal space in your system

Applications

• Water treatment plants
• Transportation industry
• Renewable energy installations
• Automotive production

What does 4PDT mean?

4PDT stands for four poles, double throw. It means the relay has four contacts that can switch four circuits on or off. You can use a 4PDT unit to change motor directions, control multiple devices or switch complex logic circuits.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	24V ac
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Series	MY
Latching	Yes
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current AC	6 A
Maximum Switching Current DC	6 A
Length	28mm
Coil Resistance	180 Ω
Coil Power	900mW
Minimum Operating Temperature	-55°C
Contact Material	Silver
Depth	36mm
Standards Met	CQC, CSA, IEC, UL

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical & LED indicators, lockable push test button, 24 VAC
