OMRON MY4IN-GS-R DC24 | Plug-In Power Relay | 24 V DC Coil, 4PDT, 6 A
OMRON MY4IN-GS-R DC24 is a 4PDT plug-in power relay built around a 24 V DC coil, with a 6 A switching current rating. It uses a 14-pin plug-in base and adds mechanical and LED indicators and a lockable push test button, with a coil resistance of 662 Ω (coil power 900 mW).
- Maximum switching voltage 250 V AC / 220 V DC
- Maximum switching current 6 A AC / 6 A DC
- Silver contacts
- Coil-to-contact isolation 2 kV AC
- Standards: CQC, CSA, IEC, UL
- 4 poles (4PDT)
- Detailed Description
- Specifications
- Features
- Downloads
OMRON Power Relay, Single Coil, 2kV AC Coil-to-Contact Isolation - MY Series - MY4IN-GS-R DC24
Features & Benefits
• Service life of 300,000 cycles, so it provides long-lasting performance
• Compatible with extreme conditions thanks to an operating temperature range of -55°C to +70°C
• Highly conductive silver contacts deliver a quality connection you can rely on
Applications
• Commercial car washes
• HVAC systems
• Counting and sorting equipment
How do I install this relay?
What are the coil and switching voltages of this component?
Note
| Brand | Omron |
| Series | MY |
| Coil Voltage | 24V dc |
| Contact Configuration | 4PDT |
| Mounting Type | Plug In |
| Switching Current | 6A |
| Number of Poles | 4 |
| Latching | Yes |
| Coil Resistance | 662 Ω |
| Terminal Type | Plug In |
| Length | 28 mm (1.10 in) |
| Coil Power | 900mW |
| Depth | 36 mm (1.42 in) |
| Contact Material | Silver |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Isolation Coil To Contact | 2kV ac |
| Maximum Switching Current DC | 6 A |
| Maximum Switching Current AC | 6 A |
| Standards Met | CQC, CSA, IEC, UL |
Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical & LED indicators, lockable push test button, 24 VDC
