OMRON SS-5-2 | Pin Plunger Micro Switch | 5 A @ 125 V ac, SPST, Solder Terminal
Rated 5 A at 125 V ac, the OMRON SS-5-2 pairs a pin plunger actuator with solder terminals in an SPST micro switch. This pin plunger model is specified for 30 million operations of mechanical life. The pin plunger model uses silver contacts.
- Contact configuration: SPST (single-pole single-throw)
- Operating force: 1.47 N; release force: 0.25 N
- Works from -25 to +85 °C
- IP40 enclosure rating
- Contact rating: 5 A at 125 V ac
- Detailed Description
- Specifications
Omron SS Subminiature Basic Switch
(5 A)
A variety of models with low operating force to high operating force are available
Solder, quick connect terminals (#110) and PCB terminals are available
| Brand | Omron |
| Actuator Type | Pin Plunger |
| Terminal Type | Solder |
| Contact Configuration | SPST |
| IP Rating | IP40 |
| Contact Current Rating | 5 A @ 125 V ac |
| Minimum Operating Temperature | -25 °C (-13 °F) |
| Maximum Operating Temperature | +85 °C (185 °F) |
| Contact Material | Silver |
| Mechanical Life | 30000000Operations |
| Operating Temperature Range | -25 → +85 °C (-13 to 185 °F) |
| Operating Force | 1.47 N |
| Release Force | 0.25N |
