Palmer Wahl TCMR-K_Meter | Heat-Prober Type K Thermocouple Meters | -100 to 2500 °F
The TCMR-K series is Palmer Wahl's pocket-sized Heat-Prober meter range for Type K thermocouples, covering -100 to 2500 °F or -70 to 1370 °C. It accepts any Type K probe with an ANSI mini-connector and updates the reading three times per second. Three versions are listed: TCMR-K (LED, NiCad, switchable °F/°C), TCMR-KX (LCD, NiCad, °F) and TCMR-KVX (LCD, 9 V alkaline, °F).
Key features
- Accuracy ±0.2% of reading ±1 digit, 1° resolution
- Permanently calibrated cold junction compensation circuit
- Peak temperature hold and low battery indicator
- NiCad models include a battery recharger
- Battery life approx. 8 h (TCMR-K) or 50 h (LCD models)
- NIST certification available
- Specifications
| Part Number | TCMR-K_Meter |
| Brand | Palmer Wahl |
| Models | TCMR-K, TCMR-KX, TCMR-KVX |
| Range | -100 to 2500 °F / -70 to 1370 °C |
| Accuracy | ±0.2% of reading ±1 digit |
| Resolution | 1° |
| Update Rate | 3 readings per second |
| Display | 0.33 in LED (TCMR-K); 0.5 in red LCD (KX, KVX) |
| Power | 6.25 V NiCad (11681-1) or 9 V alkaline (KVX) |
| Battery Life | Approx. 8 h (TCMR-K); approx. 50 h (KX, KVX) |
| Probe Connector | Type K ANSI mini-connector |
| Dimensions | 3 x 6 x 1.5 in (7.5 x 15 x 3.75 cm) |
| Weight | 10.5 oz (298 g) |
