Name: Dwyer Instruments MC2016 | Multi-Cal pressure module | 100 psig gage pressure | ±0.05
Rating: 4.7 (25 reviews)

Dwyer Instruments MC2016 | Multi-Cal pressure module | 100 psig gage pressure | ±0.05

Dwyer Instruments MC2016 | Multi-Cal pressure module | 100 psig gage pressure | ±0.05

Brand :

Stock Status : Contact us for delivery

Brand :

Stock Status :

Out of Stock

Part Number : MC2016

With its interchangeable modules, the Multi-Cal Pressure Sensor MC2016 offers a wide range of pressure ranges and accuracy levels. Two pressure modules can be stored in a portable calibrator at once. The modules come with NIST calibration certification included.

Specification
Features
Catalog

Specifications

Details

Range

100 psig gage pressure

Accuracy

±0.05

Output

RS232 serial interface, 9-pin

Alarm

Output: SPST form C 110 VDC, 120 VDC (max.), 1 A (mas.), 30 W, 62.5 VA (resistive)

Display

Alphanumeric LCD, 0.37" (9.5 mm) height per line, 2 lines, 16 characters/line

Display

Update: 100 msec

Ambient temperature

32 to 120°F (0 to 49°C)

Storage Temperature

-4 to 158°F (-20 to 70°C)

Connection

Process: 1/8" female NPT

Connection

Electrical: Miniature recessed banana jacks

Battery Life

30 hours (approx)

Measuring Units

In H2O, psi, in Hg, kPa, mbar, cm H2O, m Hg, and user-defined

Housing Material

ABS plastic

Overpressure

Differential Pressure Modules: 50 psi positive direction, 15 psi negative direction, Gage Pressure Modules: 2x range (0/5 psi to 0/1000 psi)

Sensitivity

±0.002% of span with dampening 1 part in 50,000 (max.)

Temperature

20 to 120°F (-7 to 49°C)

Temperature Error

Maximum of ±0.004% of span per °F over compensated range for zero and span

Temperature Effect

±0.001% of span per °F over compensated range

Dampening

300, 1200, 2400, or 9600, selectable

Weight

Calibrator: 2.2 lb (1.3 kg); Pressure Module: 0.5 lb (0.3 kg)

Dwyer Instruments MC2016 | Multi-Cal pressure module | 100 psig gage pressure | ±0.05 Kuwait

Part Number : MC2016

With its interchangeable modules, the Multi-Cal Pressure Sensor MC2016 offers a wide range of pressure ranges and accuracy levels. Two pressure modules can be stored in a portable calibrator at once. The modules come with NIST calibration certification included.
