Aim-TTi MX100T | Multi-Range Triple Output DC Power Supply | 3 x 35V/3A, 315W

Name: Aim-TTi MX100T | Multi-Range Triple Output DC Power Supply | 3 x 35V/3A, 315W
Brand: Aim Tti
SKU: MX100T
Availability: OutOfStock

Part Number : MX100T

The Aim-TTi MX100T is a triple output multi-range supply with three 35V/3A outputs and 315W in total, controlled from its front panel. It suits engineers who need three fully featured outputs on the bench without remote interfaces.

Key features

Three 35V/3A outputs, 315W total
No remote interfaces
Range switching gives variable voltage/current combinations
Shared power mode provides double power from a single output
Linear final regulation for low output noise and ripple
Setting resolution up to 1mV and 0.1mA; variable OVP and OCP
Output on/off control with programmable delay sequencing

Availability: in stock

Free Kuwait shipping available

Detailed Description
Specifications
Features
Downloads
FAQs

MX100TP Triple Output dc Power Supply 315 watts

The MX100TP is a 315 W precision laboratory power supply offering three full performance outputs each with multiple ranges. The MX100TP power supply has a large backlit graphic LCD, which can show full settings for all three outputs simultaneously, with a fast and intuitive user interface that includes other display modes and menu screens when required.

For an optional GPIB module see stock number 144-5481.

Three high performance outputs of 105 watts each
3 x (0 to 35V at 0 to 3A)
Total power of 315 watts in a compact package
Range switching gives up to 70 volts and up to 6 amps
Twelve range combinations for maximum flexibility
Up to 210 watts from a single output
Low output noise and ripple via linear final regulation
High setting resolution down to 1mV and 0.1mA
Variable OVP and OCP trips on all outputs
50 setting memories per output plus 50 linked memories
Selectable isolated voltage tracking)
Selectable current meter averaging
Switchable remote sense on all outputs
Graphic LCD provides simultaneous output metering
Numeric or spin-wheel control of all parameters
Individual or combined output on/off control with programmable delay sequencing.
3U half-rack case for bench or rack mounting
RS-232, USB and LAN (LXI) interfaces
Duplicate power and sense terminals at rear

Standards

EN 61010-1, EN 61326

Supplied with

User manual, mains lead, IVI driver, USB driver and other software

Aim-TTi Programmable DC Bench Power Supply

The Aim-TTi 315W rated programmable DC bench power supply has 3 outputs. It is a UKAS calibrated power supply. The output voltage rating ranges between 0V and 70V and the current rating ranges between 1mA and 6A. The values of the adjustable outputs are displayed on graphic LCD provides simultaneous output metering. The power supply offers a clean power, excellent regulation, and fast transient response.
Supplied with:
User manual, mains lead, IVI driver, USB driver and other software.

For an optional GPIB module see stock number 144-5481.

Features and Benefits

Twelve range combinations for maximum flexibility
Up to 210 watts from a single output
Low output noise and ripple via linear final regulation
High setting resolution down to 1mV and 0.1mA
Variable OVP and OCP trips on all outputs
50 setting memories per output plus 50 linked memories
Selectable isolated voltage tracking
Selectable current meter averaging
Switchable remote sense on all outputs
Numeric or spin-wheel control of all parameters
Individual or combined output on/off control with programmable delay sequencing
3U half-rack case for bench or rack mounting
RS-232, USB and LAN (LXI) interfaces
Duplicate power and sense terminals at rear

Applications

Production testing
QA verifications
R&D design verification

Certifications

EN 61010
EN61326

Supplied with

Test Bridge Logging and sequencing software

Multi instrument control

Logging to table and graph format

Timed sequence control across all instruments and channels

USB, LAN and RS232 compatible

Part Number	MX100T
Brand	Aim-TTi
Outputs	3
Output Rating	3 x 35V/3A
Total Power	315W
Regulation	Linear final regulation
Setting Resolution	Up to 1mV / 0.1mA
Memories	50 per output + 50 linked
Case	3U rack case
Interfaces	None

Low power output provides up to 12 volts or up to 3 amps
Range switching gives variable voltage/current combinations
Shared power mode provides double power from a single output
Low output noise and ripple via linear final regulation
High setting resolution of up to 1mV and 0.1mA
Three high performance outputs each with full functionality
315 watts plus of total power
Two high power outputs plus one low power output
High power outputs each capable of 30 volts at 6 amps
Range switching provides up to 120 volts or up to 20 amps

Aim-TTi MX100T | Multi-Range Triple Output DC Power Supply | 3 x 35V/3A, 315W

DOWNLOAD CATALOG

Q: What is the total power output of the Aim TTi MX100TP power supply? A: The Aim TTi MX100TP offers a total power output of 315W with three independent 105W outputs. Q: How many outputs does the MX100TP DC power supply have? A: The MX100TP features three fully programmable outputs with multiple voltage and current ranges. Q: What voltage and current ranges are supported by the MX100TP? A: Each output supports 0–35V at 0–3A, with range switching allowing up to 70V or 6A depending on configuration. Q: Is the Aim TTi MX100TP suitable for laboratory and R&D applications? A: Yes, the MX100TP is designed for laboratory testing, R&D design verification, QA testing, and production environments. Q: Does the MX100TP support remote control and connectivity? A: Yes, the power supply includes USB, RS-232, and LAN (LXI) interfaces for remote operation and automation. Q: Does this DC power supply include over-voltage and over-current protection? A: Yes, the MX100TP includes adjustable OVP (Over Voltage Protection) and OCP (Over Current Protection) on all outputs. Q: Can the outputs be controlled independently? A: Yes, each output can be individually controlled or combined with programmable sequencing options. Q: What display does the Aim TTi MX100TP use? A: The unit features a large backlit graphic LCD that displays settings and output readings simultaneously. Q: Is the MX100TP rack mountable? A: Yes, the MX100TP comes in a compact 3U half-rack form factor suitable for bench or rack mounting. Q: What industries commonly use the MX100TP power supply? A: The MX100TP is commonly used in electronics laboratories, industrial testing, research facilities, and engineering development environments.
