AVENTICS 0822340503 Pneumatic Guided Cylinder - , 32mm Bore, 80mm Stroke, TRB Series, Double Acting

Name: AVENTICS 0822340503 Pneumatic Guided Cylinder - , 32mm Bore, 80mm Stroke, TRB Series, Double Acting
Brand: Aventics
SKU: 0822340503
Availability: OutOfStock

Part Number : 0822340503

Availability: Sold out

Detailed Description
Specifications

The Aventics tie rod cylinder, ISO 15552, Series TRB, is designed to meet the demanding needs of heavy-duty industries such as automotive, mining, and machinery. With its robust construction, this cylinder ensures reliable performance in rigorous environments. The double-acting functional principle and adjustable pneumatic cushioning make it an ideal choice for automating various applications. Versatile and durable, this cylinder is compatible with standard industrial environments and offers exceptional resistance to varying temperatures and pressures. Its lightweight, yet sturdy materials provide longevity while maintaining optimal performance levels, making it an essential component for your manufacturing needs.

Engineered for heavy-duty applications across diverse industries
Double-acting design enhances efficiency and performance
Pneumatic adjustable cushioning optimises sensitivity and protection
Constructed from high-quality stainless steel for increased durability
The wide temperature range ensures reliable operation in harsh conditions
Offers a maximum working pressure of 10 bar for enhanced performance
Easy integration into existing systems with standard port sizes
Designed for minimal maintenance, saving time and cost
ATEX optional ensures compliance with explosive atmosphere standards

Brand	AVENTICS
Manufacturer Series	TRB
Model Number p	0822340503
Stroke	80mm
Bore	32mm
Action	Double
Pneumatic Connection	G 1/8
Port Connection	G 1/8
Piston Rod Thread Gender	Male
Cushioning Type	Pneumatic Cushioning
Maximum Operating Pressure	10 bar
ISO Standard	15552
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+80°C
