AVENTICS 1823373108 | Pneumatic Non-Return Valve | G 1/4 F Inlet, G 1/4 M Outlet, 0.2 to 10 bar

Name: AVENTICS 1823373108 | Pneumatic Non-Return Valve | G 1/4 F Inlet, G 1/4 M Outlet, 0.2 to 10 bar
Brand: Aventics
SKU: 1823373108
Availability: OutOfStock

Part Number : 1823373108

Fitted with a G 1/4 female inlet and G 1/4 male outlet, the AVENTICS 1823373108 NR01 non-return valve lets air pass in one direction across an operating range of 0.2 to 10 bar.

Inlet: G 1/4 female
Outlet: G 1/4 male
Operating pressure: 0.2 to 10 bar
Series: NR01

Availability: in stock

Detailed Description
Specifications
Downloads

The Aventics Non-Return valve are designed for safety relevant processes. The array of connection helps them to be screwed in separately and are also suitable for direct installation in piping.

Poppet valve
Port diameter are 8 mm and G 1 by 4
Nominal flow is 950 l per min

Brand	AVENTICS
Inlet Connection Type	Threaded
Threaded Inlet Connection	G 1/4 Female
Outlet Connection Type	Threaded
Manufacturer Series	NR01
Threaded Outlet Connection	G 1/4 Male
Operating Pressure Range	0.2 → 10bar

AVENTICS 1823373108 | Pneumatic Non-Return Valve | G 1/4 F Inlet, G 1/4 M Outlet, 0.2 to 10 bar

DOWNLOAD CATALOG

1823373108 Datasheet - 1823373108 A700000012800622

1823373108 Datasheet - 1823373108 A700000012801410
