Brannan 10/105/0 | Twaddle Hydrometer | 102 to 138 °Tw, 160 mm
Brannan 10/105/0 covers 102 to 138 °Tw on a 160 mm instrument, the fifth range in the short Twaddle series. That span equals about 1.510 to 1.690 SG, so it is aimed at dense process liquids measured in degrees Twaddle. Each mark is one degree and the hydrometer is adjusted at 60 °F.
Key features
- 102 to 138 °Tw (approx. 1.510–1.690 SG)
- 160 mm size with 1 °Tw graduations
- Calibrated for medium surface tension liquids at 15.6 °C
- Soda glass with steel shot ballast, UK manufacture
- Certificate options for 10/105/0: UKAS, traceable or statement of conformity
- Specifications
- Downloads
| Part Number | 10/105/0 |
| Brand | Brannan |
| Scale | Twaddle (°Tw) |
| Range | 102 to 138 °Tw |
| Approx. SG Equivalent | 1.510 to 1.690 |
| Divisions | 1 °Tw |
| Accuracy | ±1 °Tw |
| Overall Length | 160 mm |
| Reference Temperature | 15.6 °C (60 °F) |
| Surface Tension | Medium |
| Material | Soda glass, steel shot ballast, synthetic wax resin |
| Approx. Weight | 21 g incl. 8 g protective tube |
| Supplied In | Protective resealable plastic tube |
| Origin | Made in UK |
