Brannan 34/468/0 | General Purpose Pressure Gauge | 63 mm, -1 to 5 bar, 1/4 in BSP bottom
Part Number : 34/468/0
Brannan 34/468/0 is a 63 mm (2.5 in) general purpose pressure gauge with a -1 to 5 bar range, a bar outer and psi inner scale, and a 1/4 in BSP bottom connection. At this dial size the window is a snap-fit polycarbonate type and the accuracy class is 1.6%. Part of the PG010 commercial range, it has a black steel case, brass connection and phosphor bronze Bourdon tube, and suits dry indoor installations in heating, ventilation and air conditioning, plumbing, compressors, air filters and pneumatics.
Key features
- Black steel case with brass connection and black aluminium pointer
- Phosphor bronze Bourdon tube, designed to BS EN 837 / ASME B40.100
- Dry gauge with IP 43 protection
- Ambient and medium temperature -20 to +60 °C
- Accessories such as syphons, needle valves, gauge cocks and snubbers are available
UKAS calibration is available, as well as a certificate traceable to a recognised national standard or a statement of conformity.
For pricing, please contact our experts.
