CONCOA 605 Series | Six-Port Manifold Regulator | Single Stage, Up to 250 PSIG, Cv 1.0
Part Number : CONCOA-605-SERIES-MANIFOLD-REGULATOR
The CONCOA 605 Series is a single stage, six-port brass barstock regulator for oxygen assist and other industrial laser process gases used in welding and cutting. It controls pressure at the source, fed from liquid or high pressure cylinders, for requirements up to 250 PSIG (17 BAR).
CONCOA supplies the 605 Series against a built-up ordering code, meaning outlet range, gauges, connections and options are decided when you order.
- Balanced stem seat holds delivery pressure constant
- 316L stainless steel diaphragm and 40-micron 316L filter
- 1/2 in FNPT inlet and outlet with 1/4 in FNPT gauge ports
- Max inlet 3000 PSIG (210 BAR), Cv 1.0
- PCTFE seat and PTFE internal seals
- -40°F to 140°F (-40°C to 60°C)
For pricing, please contact our experts.
