CONCOA 8066602-01-1 | 6600 Series Cylinder Regulator | Acetylene, CGA 300, 15 PSIG Delivery
Part Number : 8066602-01-1
Part 8066602-01-1 sets up the 6600 Series Cylinder Regulator for acetylene service, pairing a CGA 300 inlet with a 9/16 in -18 (B) LH Ext outlet connection. Maximum delivery pressure is 15 PSIG (1 BAR), inlet pressure is rated to 300 PSIG (21 BAR) and the seat is PTFE. On the 8066602-01-1 version, gauge scales are 0-30 PSIG/0-200 kPa and 0-400 PSIG/0-2800 kPa.
Key features
- A forged brass body and bonnet with a Cv of 0.2
- A heavy-duty machined brass bonnet, plus a chloroprene diaphragm for steady pressure control
- Medium-large seat displacement for high flow capacity and a CAPSULE® seat design for easy maintenance
- 2 1/2 in (63 mm) brass gauges with a 25-micron sintered bronze filter
For pricing, please contact our experts.
