CONCOA 8066771-01-1 | 6700 Series Manifold Regulator | CO2/Inert Gas, 15 PSIG Delivery, LH Inlet
Part Number : 8066771-01-1
Designed for carbon dioxide and inert gas manifold supply, CONCOA 8066771-01-1 has a LH inlet position. Gauges scaled 0-30 PSIG/0-200 kPa and 0-400 PSIG/0-2800 kPa monitor this EPDM-seat model, which delivers up to 15 PSIG (1 BAR).
Key features
- A brass barstock body and a 40-micron 316L stainless steel filter
- A rugged forged brass bonnet with a balanced stem seat that steadies output as inlet pressure decays
- A chloroprene diaphragm with 1/2 in FNPT inlet and outlet ports
- 2 1/2 in (63 mm) brass gauges and 1/4 in FNPT gauge and relief ports
For pricing, please contact our experts.
