Dakota T-703-1405 | Single Element Contact Magnetic Transducer | 2.25 MHz, 3/8 in, Microdot Top

Name: Dakota T-703-1405 | Single Element Contact Magnetic Transducer | 2.25 MHz, 3/8 in, Microdot Top
Brand: Dakota Ultrasonics
SKU: T-703-1405
Availability: OutOfStock

Part Number : T-703-1405

This 3/8 in, 2.25 MHz magnetic transducer from Dakota (part number T-703-1405) is a single element contact probe. A magnetic housing keeps it in place on the bolt, and the Microdot socket is on top. Dakota rates it standard undamped (S); it is used with Dakota bolt tension monitors to track fastener stretch under load.

Key features

Frequency: 2.25 MHz
Element diameter: 3/8 in
Connector: Microdot, top
Damping: standard undamped (S)

Availability: in stock

Specifications

Part Number	T-703-1405
Brand	Dakota Ultrasonics
Frequency	2.25 MHz
Element Diameter	3/8 in
Element Type	Single element, magnetic
Probe Characteristic	Standard
Damping	S - standard undamped
Connector	Microdot, top
