Desoutter DR750-P400-C13 | Pneumatic Pistol Drill | 400 rpm, 55 Nm, 13 mm Keyed Chuck
Rated at 400 rpm and 55 Nm (40.6 ft.lbf) stall torque, the Desoutter DR750-P400-C13 (part no. 2051466584) is a pneumatic pistol drill. A keyed chuck with 13 mm maximum capacity comes fitted to the DR750-P400-C13 on its 1/2-20 mount. Built in composite with a 1/4 in air inlet, the DR750-P400-C13 is part of the Desoutter DR750 pneumatic pistol drill family.
Key features
- Uses 14 l/s (29 cfm) of air at free speed; the DR750-P400-C13 needs at least a 10 mm hose over a 5 m run
- Progressive trigger on the DR750-P400-C13, with vibration <2.5 m/s², sound level 81 dba
- DR750-P400-C13 weight 1.15 kg (2.54 lb), length 184 mm (7.24 in)
- Composite construction on the DR750-P400-C13 with 1/4 in air inlet
- Specifications
- Downloads
| Part Number | 2051466584 |
| Model | DR750-P400-C13 |
| Brand | Desoutter |
| Tool type | Pistol |
| Free Speed | 400 rpm |
| Stall torque | 55 Nm (40.6 ft.lbf) |
| Chuck type | Keyed |
| Chuck max capacity (mm) | 13 |
| Chuck mount | 1/2-20 |
| Air consumption at free speed | 14 l/s (29 cfm) |
| Weight | 1.15 kg (2.54 lb) |
| Length (L) | 184 mm (7.24 in) |
| Vibration (m/s²) | <2.5 |
| Sound Power (dba) | 81 dba |
