Dwyer 104-10 | Well-Type Portable Manometer | 0-10 in w.c., 11-1/8 in Scale
Dwyer 104-10 is a well-type (vertical) Series 100 Durablock portable manometer covering 0-10 in w.c. on an 11-1/8 in scale with .10 in minor divisions. Made of solid plastic, it handles static pressure, vacuum or differential pressure and comes in a metal carrying case.
- Range 0-10 in w.c.
- .10 in minor divisions on an 11-1/8 in scale
- Well-type solid plastic body
- Metal carrying case; weight 4 lb
- Specifications
- Features
- Downloads
| Part Number | 104-10 |
| Brand | Dwyer |
| Series | 100 Durablock |
| Type | Well-type |
| Range | 0-10 in H2O |
| Weight | 4 lb |
| Minor Division | .10 in |
| Scale Length | 11-1/8 in |
| Carrying Case | Metal |
- The 1" Thick Acrylic Plastic Body is a robust, nearly indestructible block that is not susceptible to distortion.
- The precision of the drilled bore, which is accurate to ±.0002", is unaffected by bends or curves and doesn't need to be adjusted due to distortion.
- High wetability gauge oil is chosen to create a well-shaped, constant meniscus that is easy to read.
- Easy zeroing is made simple with the thumbscrew locking adjustable reflective chrome finish scales.
- To ensure optimal precision and consistency in parallax-free reading, just line the meniscus with its reflected image in the polished metal scale.
- With reference to an integrated sensitive ground glass bubble level, the screw type leveling adjustment for inclined style gauges offers quick and precise leveling.
- Outfitted comes with a plastic carrying box and accessories.
