Dwyer 160F | Straight Stainless Steel Pitot Tube | 18" Insertion, K-Factor 0.81
The Dwyer 160F is the 18" (44 cm) straight stainless steel Pitot tube in its series, designed to slip into ducts through pressure taps and grilles and to reach tight spots where a hook-style tube will not fit.
- 18" (44 cm) insertion length, 4.3 oz (122 g)
- ±2% FS accuracy from 0 to 9000 FPM (45 m/s) with a K-factor of 0.81
- Permanently etched depth graduations on 304 stainless steel
- 1/4" OD process connection, rated to 1500 °F (815 °C)
- Specifications
- Features
- Downloads
| Part Number | 160F |
| Brand | Dwyer |
| Type | Straight Pitot Tube |
| Accuracy | ±2% FS, 0 to 9000 FPM (45 m/s) |
| Weight | 4.3 oz (122 g) |
| Process Connection | 1/4" OD |
| Approvals | RoHS II (EU Directive 2011/65/EU) |
| Insertion Length | 18" (44 cm) |
| Maximum Operating Temperature | 1500 °F (815 °C) |
| Wetted Material | 304 SS |
| K-Factor | 0.81 |
- Its straight form makes it simple to insert into ducts.
- Accurate placement is made easier by permanently stamped insertion depth graduations.
- Tip alignment with the flow is aided by the alignment indication.
