Dwyer Instruments AVUB-1-V | Air velocity transmitter | 0-785 fpm (0-4 m/s) with 0-10 VDC output | 8% accuracy
A high-velocity duct-mount air velocity transmitter with 3% of reading accuracy and universal current/voltage analog outputs. The Dwyer AVUL-3DA1 covers 1000–4000 FPM (5–20 m/s) with field-selectable velocity ranges.
Request a Quote
Call +971 6 5436933 to request pricing or confirm availability.
Part Number-AVUL-3DA1
The Dwyer AVUL-3DA1 is designed for higher-velocity supply and exhaust duct applications requiring accurate air velocity measurement and flexible analog output options. It measures air velocity from 1000 to 4000 FPM (5–20 m/s) with 3% of reading accuracy and provides universal current/voltage analog outputs for connection to compatible BMS systems and controllers.
The transmitter features a NEMA 4X (IP66) enclosure, along with an operating temperature range of 32–122°F (0–50°C) and tolerance for 5–95% RH non-condensing conditions. This makes it suitable for standard mechanical-room and plenum environments.
With a response time of approximately 4 seconds, or approximately 1 second at constant temperature, the AVUL-3DA1 is suitable for responsive AHU and fan-control applications. It operates on 24 VDC or 24 VAC with a maximum current requirement of 60 mA, supporting both retrofit projects and new installations.
This variant does not include a local display. Measurements are instead transmitted through the connected analog output to the BMS or controller. Its compact body is designed to mount into a standard duct probe assembly.
For applications requiring local readings during commissioning or maintenance, the Dwyer AVUL-3DA1-LCD provides the same 3% of reading accuracy and universal current/voltage analog outputs with an integrated 5-digit LCD display.
Key Benefits
- 3% of reading accuracy for higher-velocity duct applications
- Universal current/voltage analog outputs for flexible BMS and controller integration
- Field-selectable ranges of 1000, 2000, 3000, or 4000 FPM
- NEMA 4X (IP66) enclosure for mechanical-room and plenum applications
- Compact duct-mount design
- No onboard display for applications where readings are monitored through a connected BMS or controller
- BTL and CE approvals
Who This Product Is Best For
The Dwyer AVUL-3DA1 is suitable for controls contractors, HVAC professionals, BMS integrators, facility management teams, and building automation projects involving higher-velocity supply or exhaust ducts. It is particularly useful where flexible analog output options are required for connection to a compatible controller or BMS.
How to Use
- Mount the AVUL-3DA1 in the duct according to standard probe insertion practices.
- Connect 24 VDC or 24 VAC power and the appropriate universal current/voltage output to the BMS or controller.
- Select the required velocity range: 1000, 2000, 3000, or 4000 FPM.
- Confirm that the transmitted analog signal is being correctly received by the connected BMS or controller.
- Monitor the air velocity reading through the connected control system.
Frequently Asked Questions
What accuracy does the AVUL-3DA1 provide?
The AVUL-3DA1 provides 3% of reading accuracy across its field-selectable velocity ranges.
What velocity ranges can the AVUL-3DA1 be set to?
The transmitter can be configured for 1000, 2000, 3000, or 4000 FPM, equivalent to 5, 10, 15, or 20 m/s.
What outputs does the AVUL-3DA1 provide?
The AVUL-3DA1 provides universal current/voltage analog outputs, including 4–20 mA, 0–5 VDC, and 0–10 VDC.
What is the enclosure rating of the AVUL-3DA1?
The transmitter has a NEMA 4X (IP66) enclosure rating, suitable for standard mechanical-room and plenum installations.
Does the AVUL-3DA1 have a local display?
No. The AVUL-3DA1 does not have an onboard display. Readings are monitored through the connected BMS or controller.
What is the power requirement?
The AVUL-3DA1 operates on 24 VDC or 24 VAC, with a maximum current requirement of 60 mA.
Does GeneralTech Shop deliver the AVUL-3DA1 across the UAE?
Yes. Call +971 6 5436933 to confirm availability and delivery timelines for your emirate.
Should I choose the AVUL-3DA1 or AVUL-3DA1-LCD?
The AVUL-3DA1 is the display-free version, while the AVUL-3DA1-LCD adds a 5-digit LCD for local monitoring. Both provide 3% of reading accuracy and universal current/voltage analog outputs. Contact GeneralTech Shop if you need help selecting the appropriate version.
