Dwyer Instruments CDT-2E40 | Carbon Dioxide | Wall Mount | Universal current/voltage output | European Housing
The Dwyer CDT-2E40 is a wall-mount carbon dioxide transmitter with a European housing, a 0-2000 ppm CO₂ range and universal 4-20 mA, 0-5 VDC or 0-10 VDC output. This model is dedicated to CO₂ measurement and does not provide a temperature output, making it suitable for indoor CO₂ monitoring, demand-controlled ventilation and building automation applications. Genuine stock at General Tech Services LLC, UAE, with free UAE-wide shipping. Request a quote in under a minute - call +971 6 5436933.
Part No. CDT-2E40
Product Overview
The Dwyer Series CDT Carbon Dioxide Transmitters accurately monitor CO₂ concentration in indoor environments to support ventilation control and energy-saving applications. The CDT-2E40 is a wall-mount European housing model with a 0-2000 ppm CO₂ range and no temperature output.
A single-beam, dual-wavelength NDIR sensor automatically compensates for light-source aging effects in occupied and unoccupied buildings. The transmitter includes digital barometric pressure adjustment and field calibration capability. Its universal CO₂ output can be configured for 4-20 mA, 0-5 VDC or 0-10 VDC to suit the connected controller.
Push buttons provide access to the menu structure, while an internal DIP switch can lock the menu to help prevent unwanted changes. The backplate electrical connection simplifies installation.
The CDT-2E40-LCD is the same transmitter with an integral LCD display.
Key Benefits
- Dedicated 0-2000 ppm CO₂ measurement
- Single-beam, dual-wavelength NDIR sensor with 15-year life expectancy
- Universal 4-20 mA, 0-5 VDC or 0-10 VDC CO₂ output
- No temperature output, making it suitable for dedicated CO₂ monitoring
- Lockable push-button menu access
- Digital barometric pressure adjustment
- Field calibration capability
- European wall-mount housing
- Backplate electrical connection for simplified installation
- CDT-2E40-LCD available with integral LCD display
- Genuine Dwyer stock with free UAE-wide shipping
Who This Product Is Best For
- Demand-controlled ventilation in schools, offices, hospitals and commercial buildings
- HVAC and building automation systems requiring dedicated CO₂ monitoring
- Projects specifying European wall-mount CO₂ sensing with universal analog outputs
- LEED-driven ventilation monitoring
- Applications where temperature measurement is not required
- Installations where a local LCD display is not required
How to Specify & Commission It
- Confirm the 0-2000 ppm CO₂ range, dedicated CO₂ measurement and European wall-mount housing are suitable for the application.
- Mount the transmitter according to the installation requirements.
- Wire the power supply and select the required 4-20 mA, 0-5 VDC or 0-10 VDC CO₂ output.
- Set the barometric pressure and perform field calibration if required.
- Configure the menu and lock it with the internal DIP switch if required.
- Verify the CO₂ reading at the connected controller.
Frequently Asked Questions
What does the CDT-2E40 measure?
It measures CO₂ from 0-2000 ppm only. This model does not provide a temperature output.
What CO₂ outputs are available?
The universal CO₂ output can be configured for 4-20 mA, 0-5 VDC or 0-10 VDC.
How accurate is the CDT-2E40?
CO₂ accuracy is ±40 ppm + 3% of reading at 2000 ppm.
What sensor technology is used?
It uses a single-beam, dual-wavelength NDIR sensor with a 15-year life expectancy.
Does the CDT-2E40 have an LCD display?
No. The CDT-2E40 does not have an integral LCD. The CDT-2E40-LCD is the corresponding version with an integral LCD display.
Is the CDT-2E40 wall or duct mounted?
It is a wall-mount model with a European housing.
Can the transmitter be field calibrated?
Yes. The CDT series provides field calibration capability and digital barometric pressure adjustment.
Is genuine stock available with UAE shipping?
Yes. Genuine Dwyer stock is available through General Tech Services LLC with free UAE-wide shipping. Call +971 6 5436933 for pricing and current availability.
