Dwyer LFMC-07-A2 | Polycarbonate Flowmeter | 0.25-2.5 GPM (1-10 LPM) water, 1/2" NPT
The LFMC-07-A2 from Dwyer is a LFMC polycarbonate water flowmeter with a 0.25 to 2.5 GPM (1 to 10 LPM) span and 1/2" male NPT fittings, read off dual straight-reading GPM/LPM scales.
- LFMC-07-A2 accuracy: ±5%
- Rod and float in 316 SS, fluoroelastomer O-rings (LFMC-07-A2)
- LFMC-07-A2 maximum operating pressure: 87 psi (6 bar) at 20°C
- ABS NPT fittings and ABS float stop on the LFMC-07-A2
- Optional LFMC-07-A2 connections: 20 mm metric union, 3/4" male NPT, or 1/2" male NPT with 90° elbow
- LFMC-07-A2 weight: 4 oz (113.4 g)
- Specifications
- Features
- Downloads
| Part Number | LFMC-07-A2 |
| Brand | Dwyer |
| Series | LFMC |
| Type | Polycarbonate flowmeter |
| Range (Water) | 0.25 to 2.5 GPM (1 to 10 LPM) |
| Scales | Dual GPM and LPM |
| Accuracy | ±5% |
| Process Connection | 1/2" male NPT |
| Optional Connections | 20 mm metric union, 3/4" male NPT, or 1/2" male NPT with 90° elbow |
| Max. Operating Pressure | 87 psi (6 bar) at 68 °F (20 °C); 90° elbow fittings 116 psi (8 bar) |
| Wetted Materials | Polycarbonate body, ABS flange nut, ABS float stop, fluoroelastomer O-rings, 316 SS rod and float, ABS NPT fittings |
| Weight | 4 oz (113.4 g) |
- Low installation costs thanks to the panel mount option's 90° elbow fitting and typical in-line male NPT process connections.
- The low cost, high durability polycarbonate body and fittings are resistant to heat and chemicals.
- The flowmeter bodies' textured backgrounds improve scale readability while saving time.
- Low maintenance expenses are produced by easily cleaned bodies.
- Easy visual set point indication is made possible by an adjustable set point indicator, which reduces expensive flow reading errors for LFMC, LFMD, LFME, and LFMF.
