Dwyer LFMF-17-I2 | Polycarbonate Flowmeter | 7-70 GPM (25-250 LPM) water, 2" NPT
Dwyer LFMF-17-I2 is a polycarbonate flowmeter for water covering 7-70 GPM (25-250 LPM), with 2" male NPT process connections. It belongs to the LFMF series and reads directly on dual GPM and LPM scales.
- LFMF-17-I2 accuracy: ±5%
- Rod and float in 316 SS, fluoroelastomer O-rings (LFMF-17-I2)
- LFMF-17-I2 maximum operating pressure: 87 psi (6 bar) at 20°C
- PA66 nylon NPT fittings and polypropylene float stop on the LFMF-17-I2
- Optional LFMF-17-I2 connections: 63 mm metric union or 2" female NPT
- LFMF-17-I2 weight: 40 oz (1.1 kg)
- Specifications
- Features
- Downloads
| Part Number | LFMF-17-I2 |
| Brand | Dwyer |
| Series | LFMF |
| Type | Polycarbonate flowmeter |
| Range (Water) | 7 to 70 GPM (25 to 250 LPM) |
| Scales | Dual GPM and LPM |
| Accuracy | ±5% |
| Process Connection | 2" male NPT |
| Optional Connections | 63 mm metric union or 2" female NPT |
| Max. Operating Pressure | 87 psi (6 bar) at 68 °F (20 °C); 90° elbow fittings 116 psi (8 bar) |
| Wetted Materials | Polycarbonate body, ABS flange nut, polypropylene float stop, fluoroelastomer O-rings, 316 SS rod and float, PA66 nylon NPT fittings |
| Weight | 40 oz (1.1 kg) |
- Low installation costs thanks to the panel mount option's 90° elbow fitting and typical in-line male NPT process connections.
- The low cost, high durability polycarbonate body and fittings are resistant to heat and chemicals.
- The flowmeter bodies' textured backgrounds improve scale readability while saving time.
- Low maintenance expenses are produced by easily cleaned bodies.
- Easy visual set point indication is made possible by an adjustable set point indicator, which reduces expensive flow reading errors for LFMC, LFMD, LFME, and LFMF.
Other models in this series
Click a row to open that product.
Related Products
Dwyer LFMF-16-I2 | Polycarbonate Flowmeter | 5-45 GPM (20-180 LPM) water, 2" NPT
Dwyer LFMF-16-I2 | Polycarbonate Flowmeter | 5-45 GPM (20-180 LPM) water, 2" NPT
Dwyer LFME-14-F2 | Polycarbonate Flowmeter | 2.5-25 GPM (10-100 LPM) water, 1" NPT
Dwyer LFME-14-F2 | Polycarbonate Flowmeter | 2.5-25 GPM (10-100 LPM) water, 1" NPT
Dwyer LFMF-15-I2 | Polycarbonate Flowmeter | 2.5-25 GPM (10-100 LPM) water, 2" NPT
Dwyer LFMF-15-I2 | Polycarbonate Flowmeter | 2.5-25 GPM (10-100 LPM) water, 2" NPT
Dwyer LFME-13-F2 | Polycarbonate Flowmeter | 2-20 GPM (8-80 LPM) water, 1" NPT
Dwyer LFME-13-F2 | Polycarbonate Flowmeter | 2-20 GPM (8-80 LPM) water, 1" NPT
Dwyer LFME-12-F2 | Polycarbonate Flowmeter | 1.2-12 GPM (5-50 LPM) water, 1" NPT
