Dwyer RMC-102-SSV | Rate-Master Flowmeter | 10-100 SCFH Air, 10" Scale, Stainless Steel Valve

Part Number : RMC-102-SSV

The Dwyer RMC-102-SSV is a Rate-Master flowmeter that reads 10-100 SCFH air directly on a 10" (254 mm) scale and comes with a stainless steel valve. Suited to general-purpose gas and liquid flow indication, the RMC-102-SSV can be surface or panel mounted.

  • Range 10-100 SCFH air on the 10" (254 mm) scale, stainless steel valve fitted
  • 2% accuracy and 1/2" female NPT process connections on the RMC-102-SSV
  • RMC-102-SSV rated to 100 psi (6.9 bar) and 130°F (54°C) maximum operating conditions
  • Wetted parts of the RMC-102-SSV: polycarbonate body, Neoprene/Buna-N O-rings, stainless steel metal parts
  • RMC-102-SSV body swaps within its 10" scale size for cleaning or a range change, leaving pipework in place
  • Weighs 39 oz (1105.6 g); the RMC-102-SSV meets RoHS II (EU Directive 2011/65/EU)
Availability: in stock
Free Kuwait shipping available
For pricing, please contact our experts.
