Dwyer SVP-3 | Proportioning Solenoid Valve | 1.40 mm Orifice, Cv 0.055, 0-24 VDC
Part Number : SVP-3
Dwyer's SVP-3 uses a 1.40 mm orifice, Cv 0.055, to give flow that follows a 0-24 VDC control voltage rather than plain on/off action. Flow reaches 45.6 SCFH (21.5 LPM) for air and 11.1 GPH (700 cc/m) for water, and the valve shuts tight when power is removed, suiting chemical mixing and laboratory testing.
- Orifice 0.055" (1.40 mm), Cv factor 0.055
- Maximum flow: 45.6 SCFH (21.5 LPM) air, 11.1 GPH (700 cc/m) water
- 0-24 VDC input, 400 mA maximum current, spade-type electrical terminals (SVP-3)
- Up to 500 psig (34.45 bar) operating and 50 psid (3.45 bar) differential pressure on the 1.40 mm model
- 316 and 416 stainless steel wetted parts with Viton o-rings; 1/4" compression fittings (SVP-3)
- Process -40 to 79°C, ambient -40 to 54°C (SVP-3)
