Dwyer Instruments TUF-1000-MD | Tenant ultrasonic BTU flowmeter | DN100 pipe size and 60 m3/h permanent flow rate with Modbus® communication - generaltechuae

Dwyer TUF-1000-MD | Ultrasonic BTU Meter | DN100, 60 m³/h, Modbus

Part Number : TUF-1000-MD

Sized for DN100 pipework with a permanent flow rate of 60 m³/h, the Dwyer TUF-1000-MD is a tenant ultrasonic BTU meter that combines a flowmeter and energy calculator to record heating and cooling consumption, for example on boiler and chiller circuits.

  • DN100 flanged meter connection, permanent flow 60 m³/h
  • Supplied with Modbus communication per the listing; serial Modbus RTU or BACnet MS/TP selectable
  • Energy accuracy to EN1434/CJ128 Class 2; temperature +/-0.1 °C
  • Brass and 316L stainless wetted parts; IP65 plastic enclosure with 8-digit LED display
  • Powered by 24 VDC/VAC or a user-supplied 3.6 V lithium battery that also acts as backup
  • Process temperature 2 to 95 °C; weight 7.5 kg
Availability: in stock
Free Kuwait shipping available
For pricing, please contact our experts.
