Dwyer VA-K2 | Variable Area Flowmeter Kit | 316 SS End Fittings, 150 mm Tubes
Built with 316 stainless steel end fittings, the Dwyer VA-K2 kit pairs a fully assembled variable area flowmeter with three interchangeable 150 mm glass flow tubes. Its fluoroelastomer O-rings and PCTFE valve orifice are specific to the stainless version.
- Glass float fitted to every tube in the VA-K2, plus spare 316 SS and tantalum floats to extend flow capability
- VA-K2 also includes a high-flow valve cartridge, tripod base, tweezers, pushrod, locking tool, correlation charts and a plastic carrying bag
- VA-K2 accuracy ±2% FS at 70°F (21.1°C) and 14.7 psia; repeatability ±0.25% of reading
- Turn-down 10:1, or 20:1 with two floats installed in the VA-K2 meter
- VA-K2: 1/8" female NPT, 200 psig (13.8 bar), 250°F (121°C), vertical mounting
- Specifications
- Features
- Downloads
| Part Number | VA-K2 |
| Brand | Dwyer |
| Series | VA-K |
| Accuracy | ±2% FS @ 70 °F (21.1 °C), 14.7 psia |
| Process Connection | 1/8" female NPT |
| Maximum Pressure | 200 psig (13.8 bar) |
| Maximum Temperature | 250 °F (121 °C) |
| Repeatability | ±0.25% of reading |
| O-rings | Fluoroelastomer |
| Valve Orifice | PCTFE |
| Flow Tubes | 3 interchangeable 150 mm borosilicate glass |
| Floats | Glass standard; spare 316 SS and tantalum |
| End Fittings | 316 stainless steel |
| Turn-down Ratio | 10:1; 20:1 with two floats |
- Made of sturdy metal, offering a lightweight and long-lasting design.
- Corrosion-resistant and appropriate for a range of industrial settings.
- High flow measurement precision, guaranteeing accurate and dependable readings.
- Because it is made to work with a variety of gases, it may be used in a wide range of industries, including manufacturing, HVAC, and lab environments.
- Outfitted with a transparent sight glass to allow for visual flow rate monitoring.
