Dwyer WVT-A-02-1 | Rotary Piston Water Meter | 3/4" NPT, 0.05 gal/pulse

Part Number : WVT-A-02-1

The Dwyer WVT-A-02-1 is a 3/4" NPT plastic rotary piston water meter with a 0.05 gal/pulse output for flow verification and totalising. Built from polymer and stainless steel, the WVT-A-02-1 can be fitted vertically or horizontally, with adapter couplings supplied to change BSPP threads to NPT.

  • WVT-A-02-1 accuracy: ±2% at nominal flow, ±5% at transitional flow
  • Rated to 150 psi (1034 kPa) and 122°F (50°C) at 3/4" NPT
  • Wetted materials on WVT-A-02-1: ABS, POM, stainless steel and Buna-N
  • 0.05 gal/pulse output, 0.01 A @ 24 VAC/DC, 5 ft (1.5 m) colour-coded leads (WVT-A-02-1)
  • Weight 1.34 lb (0.6 kg)
Availability: in stock
