ifm GF711S | Inductive Proximity Sensor | 0.5 → 4 mm, 19.2 → 30 V dc

Name: ifm GF711S | Inductive Proximity Sensor | 0.5 → 4 mm, 19.2 → 30 V dc
Brand: ifm
SKU: GF711S
Availability: OutOfStock

Part Number : GF711S

The ifm GF711S is an inductive proximity sensor with detection range 0.5 → 4 mm, supply voltage 19.2 → 30 V dc and IP65, IP67 protection.

Thread Size: M12
Sensor Technology: Inductive
Body Style: Threaded Barrel
Detection Range: 0.5 → 4 mm
Digital Switching Output Type: PNP
Connection Type: M12
Supply Voltage: 19.2 → 30 V dc
Length: 70mm

Availability: in stock

Detailed Description
Specifications
Downloads

The ifm electronic fail-safe inductive sensor, designed for industrial applications, combines robust performance with exceptional reliability. Engineered to operate efficiently across a wide temperature range, it guarantees safety and effectiveness in diverse environments. The sensor's compact threaded housing ensures easy installation while offering a maintenance-free operational life for unparalleled convenience. Its advanced PNP output function features two OSSD outputs, delivering superior responsiveness to safety events. With gold-plated contacts and short-circuit protection, this unit significantly reduces the risk of damage and promotes longevity, making it an indispensable asset for any industrial setup.

For ensuring machine safety
Certified to standards such as EN 60947-5-3 and IEC 61508
Certified to ISO 13849 standard
No special actuator for electronic fail-safe sensors required
Connection to safety PLC and safe AS-i modules or safe evaluation units

Brand	ifm
Thread Size	M12
Sensor Technology	Inductive
Body Style	Threaded Barrel
Detection Range	0.5 → 4 mm
Digital Switching Output Type	PNP
Connection Type	M12
Supply Voltage	19.2 → 30 V dc
Length	70mm
IP Rating	IP65, IP67
Mounting Type	Non-Flush
Shielding	Unshielded
Switching Current	100 mA
Series	GF7
