ifm IG0012, Inductive Threaded Barrel Proximity Sensor, M18, 8 mm Detection, 2-Wire NO, 20 → 250 V ac/dc, 20

Name: ifm IG0012, Inductive Threaded Barrel Proximity Sensor, M18, 8 mm Detection, 2-Wire NO, 20 → 250 V ac/dc, 20
Brand: ifm
SKU: IG0012
Availability: OutOfStock

Part Number : IG0012

Availability: Sold out

Detailed Description
Specifications

The ifm electronic inductive sensor is designed to deliver reliable performance across a diverse range of applications. With its robust threaded housing and exceptional sensing capabilities, it guarantees precision in calculating distances and detecting objects. The sensor's optimal range of operation and durable construction ensure it withstands challenging environmental conditions, making it an ideal choice for industrial settings. Capable of functioning within a temperature range of -25 to 80 °C, it assures endurance in varied working environments. Users can also benefit from its straightforward electrical connection process, which contributes to ease of installation and maintenance.

With combined AC/DC output stage
Large operating voltage range
Two-wire technology
Wide operating temperature range
Robust metal housing for use in harsh industrial environments

Brand	ifm
Thread Size	M18
Sensor Technology	Inductive
Detection Range	8 mm
Body Style	Threaded Barrel
Output Function	NO
Digital Switching Output Type	2-Wire
Cable Length	2m
Connection Type	Pre-Cabled
Supply Voltage	20 → 250 V ac/dc, 20 → 250 V ac/dc
Length	80mm
IP Rating	IP67
Mounting Type	Non-Flush
Shielding	Unshielded
Switching Current	100 mA
Series	IG0
Switching Frequency	50 Hz
