Mitutoyo 103-149 | Outside Micrometer | 300-325 mm, 0.01 mm graduation
For length, thickness and depth measurement between 300 mm and 325 mm, the Mitutoyo 103-149 offers 0.01 mm graduation and an accuracy of ±6 µm. This mechanical outside micrometer is used in machining and mechanical engineering for parts in the 300-325 mm size band.
- Graduation 0.01 mm across 300-325 mm
- The 103-149 is specified to ±6 µm
- Ratchet stop on the 300-325 mm 103-149 micrometer for constant force
- Measuring faces of the 103-149 are carbide
- Baked-enamel finished frame on the 300-325 mm 103-149 model
- Includes a setting standard for zeroing at 300 mm
- Specifications
- Features
- Downloads
| Part Number | 103-149 |
| Brand | Mitutoyo |
| Type | Mechanical outside micrometer |
| Range | 300-325 mm |
| Graduation | 0.01 mm |
| Accuracy | ±6 µm |
| Frame | Baked-enamel finish |
| Setting Standard | Included |
| Units | Millimetre |
| Measuring Force | Ratchet stop |
| Measuring Faces | Carbide |
Baked-enamel-finished frame.
• Equipped with Ratchet Stop for constant measuring force.
• Measuring faces: carbide.
• Setting standard included on models measuring above 25 mm / 1" maximum measuring range.
