Mitutoyo  114-113 3 Flute V-Anvil Micrometer 1-1.6" - generaltechuae

Mitutoyo 114-113 | V-Anvil Micrometer | 3 Flute, 0.0001 in Graduation

Part Number : 114-113

The Mitutoyo 114-113 is a 3-flute V-anvil micrometer for the outside diameter of cutting tools such as taps, reamers and end mills. The 400 g main unit reads to 0.0001 in.

  • Inch model graduated in 0.0001 in
  • 3-flute V-anvil with 60°/108° prism angle on the 114-113
  • Flatness 0.000024 in; mass 400 g
  • Spindle lock and Ø6.35 mm spindle, 0.75 mm pitch (114-113)
  • Satin chrome Ø18 mm thimble; box, setting standard and key included with the 114-113
Availability: in stock
For pricing, please contact our experts.
