Mitutoyo 293-180-40 | QuantuMike Digital Micrometer | 0–1 in (25.4 mm), 2 mm Spindle Pitch
Part Number : 293-180-40
The Mitutoyo 293-180-40 QuantuMike covers 0–1 in (25.4 mm) and uses a 2 mm spindle pitch, so the spindle travels four times faster than on a conventional metric micrometer. This shortens approach and release time, while maximum permissible error is ±1 µm.
- Resolution 0.00005 in / 0.001 mm; accuracy ±0.00005 in
- Carbide-tipped, micro-lapped faces; flatness 0.000012 in, parallelism 0.00004 in
- Measuring force 7–12 N with spindle lock on a ø6.35 mm spindle
- ABS/INC zero, PRESET, HOLD and function lock
- Low-voltage alarm and auto power-off after 20 minutes; CR2032 battery, 265 g
