OMRON D2VW-5L2A-1HS | Short Hinge Lever Micro Switch | 5 A @ 250 V ac, SP-CO, Tab Terminal
OMRON's D2VW-5L2A-1HS is an SP-CO micro switch combining a short hinge lever actuator, tab terminals and a 5 A at 250 V ac contact rating. This tab-terminal version has IP67 ingress protection. OMRON lists a mechanical life of 10 million operations for this tab-terminal version.
- Contact configuration: SP-CO (single-pole changeover)
- Contacts made of silver alloy
- Actuation at 2.25 N, release at 0.2 N
- Temperature range -40 to +85 °C
- Contact rating: 5 A at 250 V ac
- Detailed Description
- Specifications
- Downloads
Omron Subminiature Sealed (5 A)
Sealed to IEC IP67 (wire lead type)
RoHS compliant
Switches up to 5A @ 250Vac
Contact configuration: SPDT
Approvals
| Brand | Omron |
| Actuator Type | Short Hinge Lever |
| Terminal Type | Tab |
| Contact Configuration | SP-CO |
| IP Rating | IP67 |
| Contact Current Rating | 5 A @ 250 V ac |
| Minimum Operating Temperature | -40 °C (-40 °F) |
| Maximum Operating Temperature | +85 °C (185 °F) |
| Contact Material | Silver Alloy |
| Mechanical Life | 10000000Operations |
| Operating Temperature Range | -40 → +85 °C (-40 to 185 °F) |
| Operating Force | 2.25 N |
| Release Force | 0.2N |
