Omron D4NS-1CF, D4NS Safety Interlock Switch, 2NC/1NO, Key, Plastic

Name: Omron D4NS-1CF, D4NS Safety Interlock Switch, 2NC/1NO, Key, Plastic
Brand: OMRON
SKU: D4NS-1CF
Availability: OutOfStock

Part Number : D4NS-1CF

Availability: Sold out

Detailed Description
Specifications
Downloads

Omron D4NS Series Safety-Rated Interlock Switch Safety Interlock Switch, PG13.5 Connection Type - D4NS-1CF

This safety-rated interlock switch enhances machine safety through a reliable interlocking mechanism. Featuring a robust plastic housing and a configuration of 2NC and 1NO contacts, it prevents unintended machine operation. This switch is vital for protecting personnel and equipment while ensuring compliance with industrial safety standards.

Features & Benefits

• Multi-contact models offer versatility for various applications
• Gold-clad contacts enhance electrical reliability under load
• Suitable for both standard and micro loads, increasing usability
• Environmentally friendly design free from hazardous substances
• Simplified installation with a PG13.5 connection for efficient setup
• Durable performance with over 500,000 electrical switching cycles

Applications

• Utilised in safety mechanisms within automated machinery
• Implemented in industrial equipment requiring secure access control
• Ideal for that demand environmental protection against dust and water
• Applicable in sectors that require adherence to safety directives

What electrical ratings are supported?

It supports rated operating currents of 3A AC-15 and 0.27A DC-13.

How should it be mounted for best performance?

Ensure it is securely mounted using M4 screws and avoid applying excessive force.

What type of load is suitable for this switch?

It accommodates both standard and micro loads effectively.

How many operations can it reliably perform?

It can manage up to 500,000 operations under resistive load conditions.

Brand	Omron
Lock Style	Key
Normal State Configuration	2NC/1NO
Maximum AC Voltage	240V
Connection Type	PG13.5
Housing Material	Plastic
IP Rating	IP67
Series	D4NS
Dimensions	96 x 31 x 30.6mm
Standards Met	CE
Maximum Current	10A
Minimum Operating Temperature	-30°C
Length	96mm
Width	30.6mm
Maximum Operating Temperature	+70°C
Depth	31mm
