Omron E2K-F10MC2, Inductive Flat Proximity Sensor, 10 mm Detection, NPN NC, 12 → 24 V dc

Name: Omron E2K-F10MC2, Inductive Flat Proximity Sensor, 10 mm Detection, NPN NC, 12 → 24 V dc
Brand: OMRON
SKU: E2K-F10MC2
Availability: OutOfStock

Part Number : E2K-F10MC2

Availability: Sold out

Detailed Description
Specifications
Downloads

Omron E2K-F Series Proximity Sensor, 10mm Detection Range, IP66 Protection Rating - E2K-F10MC2

This proximity sensor is a capacitive device designed for reliable detection within a 10mm range. Built with a slim profile of just 10mm in thickness, the sensor is highly suited for integration into tight spaces. It features a pre-cabled connection with a generous 5m cable length, ensuring ease of installation in industrial settings. Additionally, its robust ABS housing provides durability and protection, achieving an IP66 rating for resistance against dust and water.

Features & Benefits

• Flat design enables discreet installation in confined areas
• NPN output for easy compatibility with most control systems
• Reverse polarity protection prevents damage from incorrect wiring
• Unshielded construction simplifies installation without interference

Applications

• Used in assembly line automation tasks
• Ideal for sensor in packaging machinery
• Suitable for non-flush mounting in robotic systems
• Used in object detection in liquid and solid materials

How does the detection range influence usability in different environments?

The adjustable detection range from 4mm to 10mm allows the sensor to be fine-tuned according to specific applications, ensuring effective performance in diverse environments.

What environmental conditions can the device withstand?

It operates reliably within an ambient temperature range of -10°C to +55°C, making it functional in various industrial conditions without condensation or icing.

What materials can this sensor detect?

This sensor effectively detects both conductive and non-conductive materials, such as metals and plastics, broadening its application in various industries.

How does reverse polarity protection enhance the device's reliability?

By preventing damage if connected incorrectly, this feature ensures the sensor maintains operational integrity and reduces the risk of failures during installation.

What benefits does the IP66 rating provide in an industrial setting?

The IP66 rating ensures the sensor is dust-tight and protected against powerful water jets, enabling its use in harsh conditions and extending its operational lifespan.

Brand	Omron
Sensor Technology	Inductive
Detection Range	10 mm
Body Style	Flat
Output Function	NC
Digital Switching Output Type	NPN
Connection Type	Pre-Cabled
Cable Length	5m
Supply Voltage	12 → 24 V dc
IP Rating	IP66
Length	50mm
Mounting Type	Non-Flush
Width	20mm
Housing Material	ABS
Maximum DC Voltage	30V
Minimum Operating Temperature	-10°C
Switching Current	100 mA
Series	E2K-F
Switching Frequency	100 Hz
Reverse Polarity Protection	Yes

Omron E2K-F10MC2, Inductive Flat Proximity Sensor, 10 mm Detection, NPN NC, 12 → 24 V dc
