OMRON E3RB-DN22 | Diffuse Photoelectric Sensor | 300 mm, NPN, M12 4-Pin Connector
OMRON E3RB-DN22: a barrel-style diffuse photoelectric sensor covering 300 mm, switching via NPN output. It connects via an M12 4-pin connector and the housing is nickel-plated brass. Within OMRON's range, the E3RB-DN22 is listed under the E3RB series.
- Light source: LED
- Maximum voltage: 30 V DC
- Current rating up to 25 mA
- Response time: 500 μs
- Protection rating: IP67 and IP69K
- Operating temperature: -25°C to +55°C
- Detailed Description
- Specifications
- Downloads
E3RB Compact Radial Photoelectric Sensors
Compact design
Metal housing
Visible LED light for easy alignment
LED indication
Light-ON/Dark-ON selectable by wiring
Reversed power supply polarity protection, output short circuit protection and reversed output polarity protection
Built in amplifier
Short circuit and reverse polarity protection
M18 DIN size cylindrical housing
| Brand | Omron |
| Series | E3RB |
| Detection Type | Diffuse |
| Detection Range | 300 mm (11.8 in) |
| Sensor Style | Barrel |
| Output Type | NPN |
| Electrical Connection | M12 4 Pin Connector |
| Light Source | LED |
| Response Time | 500 μs |
| Maximum DC Voltage | 30V |
| IP Rating | IP67, IP69K |
| Maximum Current | 25 mA |
| Minimum Operating Temperature | -25 °C (-13 °F) |
| Housing Material | Nickel Plated Brass |
| Maximum Operating Temperature | +55 °C (131 °F) |
