Omron E5CC-RX3D5M-001, E5CC Panel Mount PID Temperature Controller, 96 x 96mm 2 Input, 1 Output Relay, 24 V ac/dc Supply Voltage ON/OFF,

Part Number : E5CC-RX3D5M-001

Availability: Sold out

Detailed Description
Specifications

Omron E5CC Series PID Temperature Controller, 24V Supply Voltage, Relay Output Type - E5CC-RX3D5M-001

This PID temperature controller is designed to provide precise temperature management across various industrial applications. Featuring a compact size of 96 x 96 mm, it offers rapid sampling at 50ms and is panel mountable. The device supports a wide temperature range from -200°C to +2300°C, ensuring versatility in diverse environments.

Features & Benefits

• Multi-line white display enhances readability in any lighting conditions
• Universal temperature input accommodates different sensor types
• Robust design supports IP20 and IP66 for varying operational environments
• Relay output enables reliable switching of connected devices
• Compact depth of 72.1mm allows for easy installation in tight spaces

Applications

• Used in manufacturing processes for accurate temperature verification
• Used in laboratories for research requiring precise thermal control
• Suitable for food processing industries needing consistent temperature monitoring
• Utilised in HVAC systems for optimal airflow and temperature regulation

How does the PID control function improve temperature regulation?

The PID function adjusts the control output dynamically based on the difference between the set point and the current temperature, ensuring minimal overshoot and stable operation.

Can this device handle multiple sensor types?

Yes, it supports various sensors, including PT100 thermocouples and other universal inputs, allowing for flexibility in application.

What maintenance is required for optimal performance?

Regular checks on wiring integrity and periodic calibration of sensors are recommended to maintain accuracy and prevent any operational issues.

Is this controller suitable for use in wet or corrosive environments?

The controller can be utilised in diverse environments, but waterproofing should be ensured based on specific operating conditions.

Omron - E5GC, E5CC, E5EC, E5AC, E5DC, E5CN & E5CB Ranges

Brand	Omron
Output Type	Relay
Supply Voltage	24 V ac/dc
Size	96 x 96mm
Number of Inputs	2
Number of Outputs	1
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+55°C
Temperature Range	-200 → +2300 °C
Control Type	ON/OFF, PID, 2-PID Controller
Display Type	Multi-Line
IP Rating	IP00, IP20, IP66
Range	0 → +260 (Infrared Temperature Sensor) °C, 0 → 10 V, 0 → 20 mA, -200 → +2300 (Thermocouple) °C, -200 → +850 (Platinum Resistance Thermometer) °C
Input Type	Universal, Platinum Resistance Thermometer, PT100, Thermocouple, Analogue
Mounting Type	Panel Mount
Series	E5CC
Display Colour	White
Panel Depth	72.1mm
Termination Type	Screw terminal block
