Name: Omron G7L-2A-P 200/240AC, PCB Mount Power Relay, 240V ac Coil, 20A Switching Current, DPST
Brand: OMRON
SKU: G7L-2A-P 200/240AC
Availability: OutOfStock

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron G7L-2A-P 200/240AC, PCB Mount Power Relay, 240V ac Coil, 20A Switching Current, DPST

Part Number : G7L-2A-P 200/240AC

Availability: Sold out

Detailed Description
Specifications

PCB Mounting & Plug-in - Power Relays - G7L Series

Relay compatible with momentary voltage drops up to 50% of rated voltage
High capacity and high dielectric strength
Flame-resistance UL94V-0 insulation material
Choice of connection types available - quick-connect or PCB terminals
Suitable DIN rail/surface socket (Front connecting socket) and relay mounting clip (E-bracket) available separately for use with quick-connect types G7L-1A-T and G7L-2A-T (not to be used with G7L-1A-TUB and G7L-2A-TUB upper bracket mount types)

Approvals

UL; CSA; TÜV

Brand	Omron
Coil Voltage	240V ac
Contact Configuration	DPST
Mounting Type	PCB Mount
Switching Current	20A
Number of Poles	2
Series	G7L
Latching	No
Terminal Type	Through Hole
Length	52.5mm
Depth	35.5mm
Height	41mm
Maximum Operating Temperature	+60°C
Minimum Operating Temperature	-25°C
Maximum Switching Power AC	4.4 kVA
Application	General Purpose

Omron G7L-2A-P 200/240AC, PCB Mount Power Relay, 240V ac Coil, 20A Switching Current, DPST

Omron G7L-2A-P 200/240AC, PCB Mount Power Relay, 240V ac Coil, 20A Switching Current, DPST

PCB Mounting & Plug-in - Power Relays - G7L Series

Approvals
