Name: Omron MY4-GS-R AC12, Plug In Power Relay, 12V ac Coil, 6A Switching Current, 4PDT
Brand: OMRON
SKU: MY4-GS-R AC12
Availability: OutOfStock

Omron MY4-GS-R AC12, Plug In Power Relay, 12V ac Coil, 6A Switching Current, 4PDT

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron MY4-GS-R AC12, Plug In Power Relay, 12V ac Coil, 6A Switching Current, 4PDT

Part Number : MY4-GS-R AC12

Availability: Sold out

Detailed Description
Specifications

OMRON Power Relay, 2kV AC Dielectric Strength, 100mΩ Contact Resistance - MY Series - MY4-GS-R AC12

Keep your electrical appliances running smoothly with this power relay from OMRON. It's a safe switching solution that uses a low-power signal to control a high energy load, reducing the risk of hazards. As the unit has four contacts, each with a double-throw action, it can regulate multiple circuits simultaneously. Plug-in terminals easily attach to a push-in plus socket (such as 111-3065), so you don't need any special tools to install it. A relay of this type is commonly found in applications like audio equipment and vending machines.

Features & Benefits

• Low contact resistance of 100Ω reduces energy loss and ensures reliable connections
• Lifespan of 300,000 cycles for long-lasting performance
• Safe to use in demanding settings, thanks to an operating temperature range between -55°C and +70°C
• Switching current of 6A for use in light-duty applications

Applications

• Medical devices
• Material handling equipment
• Elevators and escalators

How do I monitor the status of this relay?

This unit has a transparent case so you can spot any visible issues. There's also a mechanical indicator that makes monitoring and troubleshooting simple.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	12V ac
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Series	MY
Latching	No
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current AC	6 A
Maximum Switching Current DC	6 A
Length	28mm
Coil Resistance	46 Ω
Coil Power	900mW
Standards Met	CQC, CSA, IEC, UL
Contact Material	Silver
Height	36mm
Life	300000 cycles
