Omron MY4IN-GS-R AC12, Plug In Latching Power Relay, 12V ac Coil, 6A Switching Current, 4PDT

Part Number : MY4IN-GS-R AC12

Availability: Sold out

Detailed Description
Specifications

OMRON Power Relay, Single Coil, 46Ω Coil Resistance - MY Series - MY4IN-GS-R AC12

Are different voltages stopping flow between components in your circuitry? Hand over voltage management to this power relay from OMRON. To save your infrastructure from burnout, it's up to controlling large start-up loads such as motor control. The unit's real multi-tasker that you can hook up to multiple circuits at once thanks to its four-pole design. The transparent housing means it's easy to check on the inner workings at a glance. For safety, the coil is protected by 2kV AC isolation so that energy surges don't derail your workflow.

Features & Benefits

• Silver contacts efficiently conduct electricity and resist corrosion to support smooth switching
• 300,000 operating cycles for a long service life
• 12V AC coil voltage suits low-power applications
• Ideal for harsh environments as it handles ambient temperatures between -55°C and +70°C

Applications

• Lighting control
• Heating systems
• Power factor correction

Does this power relay fit into tight areas?

Yes, you can use it in crowded systems thanks to its compact dimensions of 28 (L) x 21.5 (W) x 36mm (H).

What's the benefit of the latching lever mechanism?

The latching lever feature means the coil only needs to be energised once to switch the circuit on or off, keeping electricity use to a minimum.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	12V ac
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Latching	Yes
Series	MY
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current DC	6 A
Maximum Switching Current AC	6 A
Length	28mm
Coil Resistance	46 Ω
Coil Power	900mW
Minimum Operating Temperature	-55°C
Height	36mm
Life	300000 cycles
Standards Met	CQC, CSA, IEC, UL
