Mitutoyo 511-745 | Dial Bore Gauge | 6.5-10", .0005"
Part No. 511-745 | Range 6.5"–10" (165.1–254 mm) | Graduation 0.0005"
General Tech Services LLC — Genuine Mitutoyo Distributor, Kuwait +965 9807 4888
Product Overview
The Mitutoyo 511-745 dial bore gauge measures internal diameters from 6.5"–10" (165.1–254 mm) with a self-centring two-point head and a 0.0005" dial indicator. Carbide contact points provide wear resistance, while the heat-insulating grip reduces heat transfer from the operator's hand by 50% to help maintain stable readings during extended inspection runs.
The two-point contact and centring guide allow the gauge head to align across the true diameter as it is gently rocked through the bore. The longer plunger stroke supports practical bore inspection, while interchangeable 0.5 mm washers allow fine step adjustment of the anvils. Optional extension rods can be used for deeper bores.
Before measurement, set the gauge against a setting ring or optional Inside Micro Checker. Typical applications include compressor casings, large valve bodies, turbine and gearbox housings. It is suitable for machine shops, power and desalination plant maintenance teams, and oil and gas service contractors in Kuwait.
For stable results, allow the Mitutoyo 511-745 and workpiece to reach the same temperature before measurement. Steel expands by approximately 11.5 μm per metre per °C. At 254 mm, a 10°C temperature difference can shift the measurement by around 29.2 μm, which can be significant when checking close-tolerance bores.
Need a larger bore range? See the Mitutoyo 511-746 for 10"–16".
Key Benefits
-
Self-centring guide helps align the head on the true diameter
-
Carbide contact point for long wear life
-
Heat-insulating grip reduces heat transfer from the hand by 50%
-
0.5 mm interchangeable washers for fine setting adjustment
-
Optional extension rods for deep-hole measurement
-
Longer plunger stroke for practical bore inspection
-
Mitutoyo 511-series design for repeatable internal-diameter measurement
Who This Product Is Best For
-
Machine shops checking compressor casings and large machined bores
-
QC teams measuring bore size, taper and ovality
-
Power and desalination plant maintenance teams
-
Oil and gas service contractors
-
Refinery and industrial maintenance workshops
-
Engine, pump and hydraulic rebuild workshops
-
Buyers standardising on Mitutoyo 511-series dial bore gauges
How to Measure a Bore With This Gauge
-
Fit the appropriate anvil or washer combination for the nominal bore size.
-
Set the gauge against a setting ring or master of known size and establish the reference.
-
Insert the gauge into the bore and gently rock it through the measuring position to identify the turning point on the indicator.
-
Record the deviation from nominal and repeat measurements at different depths to check for taper and bore variation.
Frequently Asked Questions
What range does the Mitutoyo 511-745 dial bore gauge measure?
It measures internal diameters from 6.5"–10" (165.1–254 mm).
Is a dial indicator included?
Yes. The Mitutoyo 511-745 is supplied with a 0.0005" dial indicator.
Do I need a setting ring?
For best accuracy, set the gauge against a setting ring or master of known size before measuring.
Why does the grip matter?
Heat from the operator's hand can affect the gauge. The larger insulating grip reduces heat transfer by 50%, helping maintain stable readings.
Which model should I choose if my bore is outside 6.5"–10"?
Choose a model whose measuring range brackets the required bore size. The 511-745 covers 6.5"–10". The 511-744 covers 4"–6.5", while the 511-746 covers 10"–16".
Can the Mitutoyo 511-745 be recalibrated?
Yes. It can be periodically recalibrated through an ISO/IEC 17025-accredited calibration service to help maintain traceable measurement results.
How should I store and care for the gauge?
Wipe the measuring faces clean after use, store the instrument in its case away from direct sunlight and coolant, and avoid dropping it. Check the reference before each inspection session and schedule periodic calibration as required.
How do I order the Mitutoyo 511-745 dial bore gauge in Kuwait?
Pricing is quote-based. Call or WhatsApp +965 9807 4888 with the model number and required quantity for pricing and availability.
